我们可以使用dlib来查找人脸，也就是所谓的侦测人脸，可以从下面github的地址去拿到models:人脸查找的models
dnnFaceDetector = dlib.cnn_face_detection_model_v1("./mmod_human_face_detector.dat")
faceRects = dnnFaceDetector(frameDlibHogSmall, 0)
for faceRect in faceRects:
x1 = faceRect.rect.left()
y1 = faceRect.rect.top()
x2 = faceRect.rect.right()
y2 = faceRect.rect.bottom()
dlib c++ 的代码如下所示：
String mmodModelPath = "./mmod_human_face_detector.dat";
net_type mmodFaceDetector;
deserialize(mmodModelPath) >> mmodFaceDetector;
// Convert OpenCV image format to Dlib's image format
cv_image<bgr_pixel> dlibIm(frameDlibMmodSmall);
matrix<rgb_pixel> dlibMatrix;
assign_image(dlibMatrix, dlibIm);
// Detect faces in the image
std::vector<dlib::mmod_rect> faceRects = mmodFaceDetector(dlibMatrix);
for ( size_t i = 0; i < faceRects.size(); i++ )
{
int x1 = faceRects[i].rect.left();
int y1 = faceRects[i].rect.top();
int x2 = faceRects[i].rect.right();
int y2 = faceRects[i].rect.bottom();
cv::rectangle(frameDlibMmod, Point(x1, y1), Point(x2, y2), Scalar(0,255,0), (int)(frameHeight/150.0), 4);
}
当然我们也可以用opencv的人脸检测模块来做，如果我们有GPU， 可以使用dlib的mmod来做，如果我们只有cpu，那就简单使用opencv的级联检测，不过，对于侧脸等等，检测得不是很多，不要紧，我们假定可以检测到。
假定我们已经检测到多张人脸，把图片存起来，然后去调用对齐是比较好的，以下是一个女演员图片，我们只示例来对齐
对齐的代码如下所示：
import align.detector as dt
import align.align_trans as at
import cv2
from PIL import Image
import numpy as np
#path = "./0.jpg"
path = "./b.png"
image = cv2.imread(path)
#cv2.convert
crop_size = 112
scale = crop_size / 112.0
reference = at.get_reference_facial_points(default_square=True) * scale
#img = Image.open(path)
img = Image.open(path).convert('RGB')
try: # Handle exception
_, landmarks = dt.detect_faces(img)
except Exception:
print("{} is discarded due to exception!".format(path))
if (len(landmarks) == 0): # If the landmarks cannot be detected, the img will be discarded
print("{} is discarded due to non-detected landmarks!".format(path))
else:
facial5points = [[landmarks[0][j], landmarks[0][j + 5]] for j in range(5)]
warped_face = at.warp_and_crop_face(
np.array(img),
facial5points,
reference,
crop_size=(crop_size, crop_size),
)
cv2.imshow("test",cv2.cvtColor(warped_face,cv2.COLOR_RGB2BGR))
#cv2.imshow("test",)
img_warped = Image.fromarray(warped_face)
img_warped.save("test.jpg")
cv2.waitKey(0)
可以看到结果是把人脸旋转了到了正脸，这个对于人脸识别是有作用得，也可以用在跨境追踪得reid上面，以图搜图上面。
向量搜索可以将多个点得向量从图中抽取出来，这个和reid 抽取特张向量一样，我们可以使用向量数据库来存储这些数据，也可以直接在内存中查找
下面我们假定所有图片已经被我们截取，例如使用1400协议截取得图片，我们使用上面得方法进行人脸截取，对齐，再从网络中抽取向量，我们可以使用任何一种arc face， 去建立网络训练数据，并抽取向量出来。
import os
import cv2
import numpy as np
import torch
import torch.utils.data as data
import torchvision.datasets as datasets
import torch.nn.functional as F
import torchvision.transforms as transforms
from backbone import Backbone
from tqdm import tqdm
def get_feature(data_root, model_root, input_size=[112, 112], embedding_size=512):
device = torch.device("cuda:0" if torch.cuda.is_available() else "cpu")
# check data and model paths
assert os.path.exists(data_root)
assert os.path.exists(model_root)
print(f"Data root: {data_root}")
# define image preprocessing
transform = transforms.Compose(
[
transforms.Resize(
[int(128 * input_size[0] / 112), int(128 * input_size[0] / 112)],
), # smaller side resized
transforms.CenterCrop([input_size[0], input_size[1]]),
transforms.ToTensor(),
transforms.Normalize(mean=[0.5, 0.5, 0.5], std=[0.5, 0.5, 0.5]),
],
)
# define data loader
dataset = datasets.ImageFolder(data_root, transform)
loader = data.DataLoader(
dataset, batch_size=1, shuffle=False, pin_memory=True, num_workers=0,
)
print(f"Number of classes: {len(loader.dataset.classes)}")
# load backbone weigths from a checkpoint
backbone = Backbone(input_size)
backbone.load_state_dict(torch.load(model_root, map_location=torch.device("cpu")))
backbone.to(device)
backbone.eval()
# get embedding for each face
embeddings = np.zeros([len(loader.dataset), embedding_size])
with torch.no_grad():
for idx, (image, _) in enumerate(
tqdm(loader, desc="Create embeddings matrix", total=len(loader)),
):
embeddings[idx, :] = F.normalize(backbone(image.to(device))).cpu()
# get all original images
images = []
for img_path, _ in dataset.samples:
img = cv2.imread(img_path)
images.append(img)
return images, embeddings
抽取完了以后，我们可以再使用比较排序等方法进行搜索，当然，可以使用向量数据库等等方法，这里假定都在内存里面,我们使用一下函数来搜索相似度，也可以使用各种排序方法。这里只是示例。
def visualize_similarity(tag, input_size=[112, 112]):
images, embeddings = get_feature(
data_root=f"data/{tag}_aligned",
model_root="checkpoint/backbone_ir50_ms1m_epoch120.pth",
input_size=input_size,
)
# calculate cosine similarity matrix
cos_similarity = np.dot(embeddings, embeddings.T)
cos_similarity = cos_similarity.clip(min=0, max=1)
# plot colorful grid from pair distance values in similarity matrix
similarity_grid = plot_similarity_grid(cos_similarity, input_size)
# pad similarity grid with images of faces
horizontal_grid = np.hstack(images)
vertical_grid = np.vstack(images)
zeros = np.zeros((*input_size, 3))
vertical_grid = np.vstack((zeros, vertical_grid))
result = np.vstack((horizontal_grid, similarity_grid))
result = np.hstack((vertical_grid, result))
if not os.path.isdir("images"):
os.mkdir("images")
cv2.imwrite(f"images/{tag}.jpg", result)
def plot_similarity_grid(cos_similarity, input_size):
n = len(cos_similarity)
rows = []
for i in range(n):
row = []
for j in range(n):
# create small colorful image from value in distance matrix
value = cos_similarity[i][j]
cell = np.empty(input_size)
cell.fill(value)
cell = (cell * 255).astype(np.uint8)
# color depends on value: blue is closer to 0, green is closer to 1
img = cv2.applyColorMap(cell, cv2.COLORMAP_WINTER)
# add distance value as text centered on image
font = cv2.FONT_HERSHEY_SIMPLEX
text = f"{value:.2f}"
textsize = cv2.getTextSize(text, font, 1, 2)[0]
text_x = (img.shape[1] - textsize[0]) // 2
text_y = (img.shape[0] + textsize[1]) // 2
cv2.putText(
img, text, (text_x, text_y), font, 1, (255, 255, 255), 2, cv2.LINE_AA,
)
row.append(img)
rows.append(np.concatenate(row, axis=1))
grid = np.concatenate(rows)
return grid
if __name__ == "__main__":
parser = argparse.ArgumentParser()
parser.add_argument(
"--tags",
help="specify your tags for aligned faces datasets",
default="test",
nargs='+',
required=True
)
args = parser.parse_args()
tags = args.tags
for tag in tags:
visualize_similarity(tag)
其他小伙伴如果有需要，我可以把代码发一下，给我留言即可。
